Absima 1/8 Monster Truck ASSASSIN Gen2.1 6S RTR

Absiman 1/8 Harjaton neliveto RTR Monsteri.

Tässä autossa ei tule mukana akkua eikä laturia, mutta on muuten suoraan paketista ajovalmis.

CHASSIS CONCEPT:
The chassis is fully tuneable with adjustable ride height, tunable shocks, adjustable camber, adjustable toe angle and multiple shock mounting positions.
Durable aluminum parts like the 3mm laser-engraved chassis plate, golden colored wheel hubs wishbone brackets, brace- and damper parts, ensure a long chassis life and a premium design.

DRIVE CONCEPT:
The drive concept - powered by HOBBYWING is top in it´s class for performance and reliability and accelerate the vehicle up to 110 km/h. The cooling fan on the 150A speed controller keeps temperatures consistent during full throttle 6S action. The 2100KV motor delivers insane power to the wheels.
The recommendations for the optional high-speed reduction (pinion is included in the scope of delivery) apply to operation on hard, level surfaces. Do not use for off-road, bashing or continuous start/stop riding, as this may damage the drive units (controller/motor)!
Parameters like brake force, drag brake, start mode (punch), running mode and LiPo cut-off you could change the settings through a set button or a programming box (separately available). XT60 connectors provide a reliable connection between your speedo and your choosen battery packs. So much power want to be supplied! We advise to quality batteries with high capacity and a C-rate of at least 45C.

5.0mm CVD shafts front and rear, CNC machined spur- and metal differential gears and 4.5mm center dogbones are used for power transmission.
"Easy-Use" motor mount concept for a quick and easy motor removal. Just open 2 screws and slide it out!
A high-speed pinion gear is included for high speed running on hard, flat surfaces. For off-road or high-load repetitive start-stop driving we recommend the standard pinion which is installed as standard!
STEERING CONCEPT:
Our proven ABSIMA "CR2SV2" 2.4 GHz radio system guarantees a fast and reliable connection to your vehicle. The 15kg metal gear servo with aluminum horn and durable high-performance tires ensure proper steering on any surface.

Get your ABSIMA ASSASSIN 6S Monster Truck and experience a whole new level of quality and performance!

Extremly durable composite plastic parts
Monocoque suspension arms
Wheely bar
Fully adjustable chassis concept
CNC machined spur gear and metal motor pinion
Adjustable oil-filled 16mm "Aluminum Big Bore" shocks
3 full-metal geared differentials
2-piece sliding motor mount concept for easy adjustment and instalation
Massive 5.0mm CVD axles - front & rear
4.5mm middle steel drive shafts - front & rear
Race compound low profile tires
"Saddle-Pack" battery concept for a perfect weight distribution
3mm black aluminum chassis plate with ABSIMA laser engravings
Aluminum servo arm
Seperate water- and dust-proof receiver box
Completely ball bearing mounted
Chassis sideguards for dirt protection
All aluminum parts anodized in gold
Aluminum 17mm wheel hex drives
Steel turnbuckles all-over
Adjustable camber, toe angle & ride height
High-Speed Pinion included
SPEED UP TO 110 KM/H





ABSIMA "CR2SV2" 2.4GHz A.F.H.D.S. radio system (servo reverse and dual rate function; foam steering wheel)
Water-proof 150A HOBBYWING speed controller (BEC: 6V/4A; programmable features: LiPo cut-off, runing mode, brake force, drag brake, punch)
Powerfull 2100KV 4-pole sensorless brushless motor (600W, Shaft Ø: 5mm, Module 1)
15kg / metal gear steering servo (25T outdrive) with aluminum servo arm

Scale: 1:8
Drive type: 4WD
Surface: Off-road
Wheelbase: 375mm
Chassis clearance: 45mm
Tire width: 82mm
Tire Ø: 165mm
Steel motor transmission: Pinion: 13T / Spur gear: 49T
Pinion module: 1.0
Length: 555mm
Width: 445mm
Height: 205mm
Weight: 4430g (w/o batteries)

ASSASSIN Gen2.0 Monster Truck - 6S Version
2.4GHz Radio System "CR2SV2"
High-Speed Pinion
Manual


2x 11.1V LiPo batteries with XT60 plugs (We recommend item 4140014 - LiPo Stick Pack 11.1V-45C 5000 Hardcase XT60)
Suitable charger (We recommend item 4000013 - Charger APC-1 + item 3040025 - XT60 adaptor)
LiPo charging bag (We recommend item 9000008 - LiPo Safety Bag)
Optional programm box for easy setup (Item 2110041)
4pcs. AA batteries for transmitter
THE "ASSASSIN" MONSTER TRUCK - A MEAN MASCHINE IS COMING!
